B1030 Portable Airborne Particle Counter

The B1030 Portable Airborne Particle Counter from Zetron supplier is a portable device specially designed to detect 0.1μm sized particles in the air. It combines advanced sensing technology and convenient operation methods to provide users with efficient and accurate particle detection methods.

Model:B1030

Send Inquiry

B1030 Portable Airborne Particle Counter Factory

>The B1030 0.1μm Portable Airborne Particle Counter is a new type of Airborneparticle counter that measures the size and number of Airborneparticles in a unit volume of air in a clean environment,with a minimum particle size range of 0.1 μm.The product features a very user-friendly interface,a high-resolution largeformat colour touch screen,easy to operate and simple to use.At the same time,this instrument can simultaneously monitor the number of particles and their changes in 6 particle size channels.

>The 0.1um monitor is mainly used for the AR glass lens manufacture,and semiconductor chip manufacture.

>The six-grain channel can be displayed simultaneously,with a minimum particle size of 0.1μm.

>The B110 is the 28.3 L,PM 0.1 micron portable designed for continuous use. >High-capacity data storage with a storage capacity of at least 100,000 units.

>Data transfer to a USB Flash Drive can be accomplished by using the software.

>Flexible communication with these instruments is made possible by the integrated Ethernet, RS-485,USB and WIFl.

>B110 Series are designed,manufactured and calibrated to ISO14644 to ensure particle counting accuracy.

>B110 Series are adopted the industry's Ul(User Interface)to configure andoperate the instrument.The intuitive ICON-driven screens and menus are easy to learn and use,and support multiple languages.

Model	B110 Laser AirborneParticle Counter
Size Range	0.1 (μm)
Channel Size	0.1,0.2,0.3,0.5,1.0,5.0(μm)
Flow Rate	28.3L/min
Concentration Limits	35,000/L @10%count loss
Liaht Source	Laser diode (30,000 hours mean time between failure
Dimensions	250215220mm(wxhxd)
Weight	5.6kg
Sample Period	1~999s adjustable
Calibration Count Mode	Meets ISO 14644 calibration,GMP-2010
Data Storage	100,000 units,Data can be exported via USB disk or printed directly
Communication Mode	RS232
Storage Environmental Temperature &Humidity	Temperature:-15~60℃; Humidity:0~98%(not condensation)
Working Environment	Temperature:5~35℃;Humidity:20~95%(not condensation)
Display	Color TFT touch screen display
Reports	Pass/fail report wizard for ISO-14644 &FS-209E report formats
Self-Cleaning Time	≤10min	Gear Counting Efficiency			50±20%
Enclosure	304 stainless steel		Printer	Built in thermal printer
Power	220V±10%;built-in lithium battery,battery life >3h
Language	English/Chinese/Customize
Standard Configuration	Packing box,operationmanual,factory calibration report,source line,sampling frame,printing paper,etc
