Portable Particles Detector

Detection Gas:PM2.5 & PM10

Portable Particles Detector FEATURES:

● ISO,CE,FCC, ROHS, ATEX,CNEX,SIL3 Approved

● Upto5 gases simultaneously detection

● Built-in pump with 800ml/m flow rate

● Sound, light and vibrationalarms (95 dB at 30 cm)

● Alarm types: LOW, HIGH, TWA,STEL

● USB communication and battery charging port

● Optional Wifi, 4G, Lora wireless transfer

● PC software for data acquisitio● and analysis

● Rechargeableand detachablebatterywith UN38.3 & MSDS certification

● 2.5 inch colorful large digital display

● Unit switch

● Automatic calibration with calibration system or manual calibration

● 100,000 piecesdata recordingfunction

● Man fell down alarm function

● Anti-drop height:≥8 meters

● OperatingEnvironmental: -40 to 70°C; ≤ 0 to 95% humidity

● Shockproof housing

● Easy-to-use buttons, even with gloves

● Exia II CT4 Ga /Ex ib I Mb

● Single gas detector: PM2.5 & PM10

● Detection principle:PM2.5 & PM10: laser laser, 0-1000ug/m3, 1ug/m3 resolution

● Accuracy:≤±2% (F.S)

● Respond time: T90≤30S

● Sensor lifetime: 2-3 years

● Detection method:Pumped

● Battery: 3.6V,5500mAh

● Protection level: IP66

● Product Size:180x78x33mm(L×W×H)

● Weight: 350g

● Anti-drop height:≥8 meters

● Working environment: -40℃～+70℃,≤95%RH (non-condensing occasions)

● Warranty time: 1 year
